TRIPP

Tripp Lite B120-000 Dvi Dual Link Extender, Dvi F/F

Returns / Exchanges: Sealed Product Only

SKU:037332130297

$98.03 CAD

~~$0.00 CAD~~ $98.03 CAD

Sale Sold out

Shipping calculated at checkout.

Product variants

Quantity

AMAZON.CA PRODUCT DESCRIPTION

null

FROM THE MANUFACTURER

Don't let distance make your application fizzle—extend a high-quality DVI Single Link video up to 135 ft. further than the 16-ft. DVI distance limitation! This Tripp Lite DVI Single Link Signal Extender delivers peak video performance by DVI-enabled digital video components, which makes it ideal for digital signage applications in schools, churches, retail displays, trade show presentations and more. The signal extender can add an extra 135 ft. to your application while the built-in signal booster can support resolutions of up to 1920x1200 (60Hz), assuring that you enjoy crystal-clear picture at all points of your installation. The B120-000 is completely plug-and-play, making it easy and efficient to set up. Additionally, the B120-000 is manufactured in compliance with strict RoHS (Restriction of Hazardous Substances) guidelines to minimize the use of hazardous materials.

The Smart Solution for Digital Signage Applications

Click here for a larger image

KEY FEATURES

THE SMART SOLUTION FOR DIGITAL SIGNAGE APPLICATIONS

The B120-000 extends a DVI Single Link video signal up to 135 ft., making it the ideal solution for digital signage applications requiring displays connected far away from a DVI source ranging from schools and churches to retail, point-of-sale displays and trade show presentations. The B120-000 allows the video source to be in a secure, remote location for controlled access while still delivering a signal to devices in another area.

GREATER FLEXIBILITY

This Tripp Lite DVI Single Link Signal Extender allows extension of a DVI signal beyond regular distance limitations. With its built-in signal booster, the B120-000 can extend a WUXGA 1920 x 1200 (60Hz) resolution up to 135 ft. away from its source. When used with a B116-series splitter, the B12-000 can be placed up to 114 ft. away from the splitter and up to 16 ft. away from the connected monitor, allowing for up to 150 ft. of cabling and even greater application distance and flexibility. For maximum distance and quality, use with Tripp Lite 50 and 100-ft. DVI cables (P561-050 and P561-100).

CONVENIENT PLUG-AND-PLAY SETUP

With no software or drivers to install, the B120-000's plug-and-play setup gets your application up and running faster. Simply connect the unit's external power supply (requires nearby power outlet), then connect the unit to the video source and to the remote displays and watch as the B120-000 provides crystal clear resolution. The B120-000 is compatible with all Tripp Lite B120- and B140-series DVI splitters and extenders to provide greater convenience and functionality. With the unit's HDCP compliance, you can be assured that you'll be up to speed with the latest digital video technology and protocol.

ENVIRONMENTALLY RESPONSIBLE

The B120-000 is manufactured in compliance with strict RoHS (Restriction of Hazardous Substances) guidelines to minimize the use of hazardous materials.

TECHNICAL SPECIFICATIONS

TRIPP LITE B120-000 DVI SINGLE LINK SIGNAL EXTENDER

Click here for a larger image

WHAT'S IN THE BOX

* B120-000 DVI Single Link Signal Extender

* External Power Supply (Input: 100-240V, 50/60Hz, 0.5A Output: 5V, 2A)

* Owner's Manual

TRIPP LITE CONNECTS ALL YOUR ELECTRONICS

B120-000-SL DVI DUAL LINK SIGNAL EXTENDER (DVI F/F)

Extend DVI signals an additional 150 ft. beyond the 16-foot distance limitation. Supports resolutions up to 1920 x 1200 and features built-in image equalization. Ideal for digital signage applications or any application that requires longer DVI cables such as classrooms and churches. HDCP-, TAA-compliant and comes with external AC power supply. 1-year limited warranty.

B140-101 DVI OVER CAT5 PASSIVE EXTENDER KIT

Extends a DVI-D Single Link signal up to 100 ft. at 1024 x 768 (60Hz) resolutions, or up to 50 ft. at 1920 x 1080 (60Hz) resolutions. Includes both the local transmitter and remote receiver units. The extender kit is compatible with all operating systems and requires no software or drivers. Does not require an external power supply. The B140-101 is HDCP and DDC compatible and also TAA-compliant for GSA schedule purchases. 1-year limited warranty.

B140-101-WP DVI OVER CAT5 PASSIVE EXTENDER WALLPLATE KIT

Wallplate form factor for easy mounting in standard in-wall electrical boxes or surface mount boxes. Extends a DVI-D Single Link signal up to 100 ft. at 1024 x 768 (60Hz) resolutions, or up to 50 ft. at 1920 x 1080 (60Hz) resolutions. Includes both the local transmitter and remote receiver units. The extender kit is compatible with all operating systems and requires no software or drivers. Does not require an external power supply. The B140-101-WP is HDCP and DDC compatible and also TAA-compliant for GSA schedule purchases. 1-year limited warranty.

P560-010 DVI DUAL LINK CABLE (DVI-D M/M)—10 FT.

This high-speed DVI Dual Link Cable is for use with Dual or Single TMDS Link specified equipment. Gold-plated copper contacts ensure excellent conductivity while the cable is molded with foil/braid shielding for maximum EMI/RFI line noise protection. This cable is PC and Mac compatible and for use with digital CRT displays, flat panel displays, HDTVs and projectors. Lifetime limited warranty.

TLP810NET PROTECT IT!™ A/V SURGE SUPPRESSOR

Economical protection for A/V components and all electronics. This surge suppressor features a high-impact plastic housing, 3240-joule surge protection rating, 8 outlets with built-in safety covers, gold coaxial surge protection, tel/DSL (RJ11) surge protection and tel/Ethernet (RJ45) surge protection, and 10-ft. power cord with right-angle plug. $250,000 Ultimate Lifetime Insurance; lifetime warranty.

SMART1000LCD SMART DIGITAL UPS SYSTEM

Automatic Voltage Regulation and battery backup protection for PCs, A/V components and all electronics. The SMART1000LCD provides 1000VA/500W power capacity with 8 outlets (4 UPS/surge, 4 surge only) plus single-line tel/DSL (RJ11) and coaxial protection. A large illuminated LCD display shows power and UPS operating conditions in real time. One USB port with included cable and PowerAlert monitoring software enables safe unattended system shutdown and file saves. The SMART1000LCD supports entry-level PCs for up to 60 minutes during power failures. $250,000 Ultimate Lifetime Insurance; 3-year warranty.

B120-000
